934674

Activated carbon

Manufacturer: Sigma Aldrich

Synonym(S): Activated carbon, Activated carbon anode

Select a Size

Pack Size SKU Availability Price
1 EACH 934674-1-EACH In Stock ₹ 25,016.58

934674 - 1 EACH

₹ 25,016.58

In Stock

Quantity

1

Base Price: ₹ 25,016.58

GST (18%): ₹ 4,502.984

Total Price: ₹ 29,519.564

material

copper substrate

Quality Level

100

grade

battery grade

description

Description/Nominal Voltage: 0.3 V vs Li/Li+

Assay

≥98%

composition

Active material loading 5.7 mg/cm2 ± 5%

greener alternative product characteristics

Design for Energy EfficiencyLearn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

size

5 in. × 10 in.

thickness

10 μm , copper current collector90 μm , (excluding current collector)

Related Products


Sigma Aldrich

934666

electrode sheet, copper substrate, ...


Sigma Aldrich

934712

--


Sigma Aldrich

934690

electrode sheet, copper substrate, ...


Sigma Aldrich

934755

--


Sigma Aldrich

934771

--


Sigma Aldrich

934682

electrode sheet, aluminum substrate...


Sigma Aldrich

934739

--


Sigma Aldrich

765171

electrode sheet, aluminum substrate...

Description

  • General description: We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Click here for more information.
  • Application: Activated carbon is used as anode in rechargeable batteries due to its many advantageous properties such as a very low insertion/deinsertion potential, large surface area, high pore density, good conductivity, low cost, and good mechanical and chemical stability compared to other alternatives. Experimentally it has been observed that by using activated carbon electrode, the diffusion co-efficient of potassium ion in potassium ion batteries improved by 7 times and could deliver a a high reversible capacity of 100 mAh/g after 100 cycles (at a high current density of 0.2 A/g), and exhibits increased rate performance. In addition, owing to the typical characteristic of porous structure, activated carbon (AC) is widely used for supercapacitor electrode and also possesses the potential as anode material in lithium ions batteries (LIBs).

SAFETY INFORMATION

WGK

WGK 2

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable
