4463169
Koehler™ Instrument Ramsbottom Carbon Residue Apparatus
Determines thecarbon residueleft after evaporation and pyrolysis of a sample oil in the Ramsbottom furnace, providing an indication of the deposit forming tendencies of fuels and guidelines for the processing of refinery products.
Manufacturer: Fischer Scientific
The price for this product is unavailable. Please request a quote
Type
Ramsbottom Carbon Residue Apparatus
Capacity
Five coking bulbs
Height (English)
14.5 in.
Width (English)
21.5 in.
Weight (English)
64 lb.
Calibration
Yes
Certifications/Compliance
ASTM D524, D6074; IP 14; ISO 4262; FTM 791-5002; NF T 60-117
Height (Metric)
37 cm
Width (Metric)
55 cm
Weight (Metric)
29 kg
Related Products
Description
- Thermostatically controlled coking furnace for five samples Cast-iron block type furnace rapidly reaches the standard test temperature of 550°C (1022°F) and controls with ±1°C stability Microprocessor temperature control has °C/°F switchable digital setpoint and display Operator and equipment are protected by an overtemperature control circuit which automatically interrupts power to the unit, should block temperature exceed the programmed cut-off point RS-232 Communications software, ramp-to-set and other enhanced features are available (sold separately) Replacement control bulb (13-187-10) sold separately Specifications: Dimensions: 16L x 21.5W x 14.5 in.H (41 x 55 x 37cm) Net Weight: 64 lb
- (29kg) Shipping Weight: 78 lb
- (35kg) Shipping Dimensions: 8.2 cu
- ft
- Compliance Conforms to ASTM D524 and related specifications.
