406074

Carbon nanotube, multi-walled

Name: Carbon nanotube, multi-walled | Sigma Aldrich | Chemikart
Brand: Chemikart

powdered cylinder cores, 20-30% MWCNT basis, O.D. × L 7-12 nm × 0.5-10 μm, avg. no. of layers, 5 ‑ 20

Manufacturer: Sigma Aldrich

CAS Number: 308068-56-6

Synonym(S): MWCNT, MWNT, Multiwall carbon nanotube

Select a Size

Pack Size	SKU	Availability	Price
500 MG	406074-500-MG	In Stock	₹ 11,666.10

406074 - 500 MG

₹ 11,666.10

In Stock

Quantity

Base Price: ₹ 11,666.10

GST (18%): ₹ 2,099.898

Total Price: ₹ 13,765.998

Quality Level

100

Assay

20-30% MWCNT basis

form

powder

feature

avg. no. of layers 5 ‑ 20

composition

carbon content, >99% TGA

O.D. × L

7-12 nm × 0.5-10 μm

avg. part. size

−270 mesh<53 μm

mp

3652-3697 °C (lit.)

density

~2.1 g/mL at 25 °C (lit.)

Other Options

Product Name	Manufacturer	Price Range
Strem, An Ascensus Company CAS# 308068-56-6. 1g. Carbon nanotubes, multi-walled (diameter = ~140nm, length = ~7 microns) (>90% nanotubes). MFCD00133992	Strem, An Ascensus Company	₹ 13,860.72
Strem, An Ascensus Company CAS# 308068-56-6. 250mg. Carbon nanotubes, multi-walled (diameter = ~10-25nm, length = ~3-8 microns) (min. 85% nanotubes). MFCD00133992	Strem, An Ascensus Company	₹ 15,914.16
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube array, multi-walled vertically aligned on Si substrate, H 0.5 mm \| 308068-56-6 \| 1EA	Sigma Aldrich Fine Chemicals Biosciences	₹ 73,802.34
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, multi-walled >90% carbon basis, D x L 110-170 nm x 5-9 mum \| Purity: >90% carbon basis \| 308068-56-6 \| 10G	Sigma Aldrich Fine Chemicals Biosciences	₹ 41,992.85
Sigma Aldrich Fine Chemicals Biosciences Carbon Nanotube, Multi-Walled \| 308068-56-6 \| 1g	Sigma Aldrich Fine Chemicals Biosciences	₹ 19,075.60
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube sheet aligned, size x thickness 100 mm x 100 mm x 1-5 mum \| Purity: >95% (carbon) \| 308068-56-6 \| 1EA	Sigma Aldrich Fine Chemicals Biosciences	₹ 98,638.70
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled \| 308068-56-6 \| MFCD00133992 \| 250 mg	Sigma Aldrich Fine Chemicals Biosciences	₹ 18,865.98
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled 98% (Semiconducting) \| Purity: 2% (Metallic); 98% (Semiconducting) \| 308068-56-6 \| 1MG	Sigma Aldrich Fine Chemicals Biosciences	₹ 87,230.13
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled carbon >=85 %, >70% (carbon as SWNT), diam. 1.3-2.3 nm \| 308068-56-6 \| 25G	Sigma Aldrich Fine Chemicals Biosciences	₹ 99,143.51
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled >70 wt. % carbon basis, D x L 2-10 nm x 1-5 mum , bundle dimensions \| 308068-56-6 \| 1G	Sigma Aldrich Fine Chemicals Biosciences	₹ 44,662.32

...

Related Products

Sigma Aldrich

412988

as-produced cathode deposit, >7.5% ...

Sigma Aldrich

901002

flake of bundled CNTs, >95% carbon ...

Sigma Aldrich

659258

>90% carbon basis, D × L 110-170 nm...

Sigma Aldrich

755710

>70% (TGA), avg. no. of layers, 1...

Sigma Aldrich

698849

>98% carbon basis, O.D. × L 6-13 nm...

Sigma Aldrich

755133

thin, <5% Metal Oxide(TGA)...

Sigma Aldrich

698695

>70 wt. % carbon basis, D × L 2-10 ...

Sigma Aldrich

750492

<3.5% Metal Catalyst, avg. no. of l...

Description

General description: Multi-walled carbon nanotube core surrounded by a fused carbon shell, the remainder being multi-layer polygonal carbon nanoparticles and amorphous and graphitic carbon nanoparticles.It contains approximately 5-20 graphitic layers. Carbon nanotubes produced by arc discharge technique contain very low impurity and possesses very high crystallinity. 4
Application: Bundles of MWNTs were trapped and manipulated to form nanotube ropes using optical tweezer.[1] MWNTs were calcined and sonicated to form carbon nanoribbons. The nanoribbons were used to fabricate array of 98 source and drain electrodes on a 300 nm SiO2/p++Si substrates.2 A MWNT probe was fabricated on Si cantilevers.[2]
Physical form: Approximately 5-20 graphitic layers. Contains approximately 10-40% tubes, the remainder being multi-layer polygonal carbon nanoparticles and amorphous and graphitic carbon nanoparticles.
Preparation Note: Electric Arc Discharge Method
Other Notes: We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.

SAFETY INFORMATION

WGK

WGK 3

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves
