900788

Carbon nanotube, few-walled

carbon ≥95 %, D × L 2.5-3 nm × 2-6 μm

Manufacturer: Sigma Aldrich

CAS Number: 308068-56-6

Synonym(S): FWCNT, FWNT, Few wall carbon nanotubes, Few-walled carbon nanotubes, Signis® FW100

Select a Size

Pack Size SKU Availability Price
250 MG 900788-250-MG In Stock ₹ 10,145.40
1 G 900788-1-G In Stock ₹ 32,356.50

900788 - 250 MG

₹ 10,145.40

In Stock

Quantity

1

Base Price: ₹ 10,145.40

GST (18%): ₹ 1,826.172

Total Price: ₹ 11,971.572

description

Deposition temp: 550 ± 50 °CG/D ratio: ≥10 (Raman)Median number of walles: 2 to 3 (TEM)

Quality Level

100

Assay

≥94% (carbon as CNT by TGA)

form

powder

composition

Carbon, ≥95% TGA carbon, ≥95%

sheet resistance

≤350 Ω/sq, at 0.15 g/m2 (Buckypaper)

D × L

2.5-3 nm × 2-6 μm

surface area

≥700 m2/g , BET

impurities

≤5 wt. % moisture content (TGA)

bulk density

0.05 g/cm3 (ASTM D7481)

Other Options

Image Product Name Manufacturer Price Range
50-901-08799
Strem, An Ascensus Company CAS# 308068-56-6. 1g. Carbon nanotubes, multi-walled (diameter = ~140nm, length = ~7 microns) (>90% nanotubes). MFCD00133992
Strem, An Ascensus Company ₹ 13,860.72
50-901-08801
Strem, An Ascensus Company CAS# 308068-56-6. 250mg. Carbon nanotubes, multi-walled (diameter = ~10-25nm, length = ~3-8 microns) (min. 85% nanotubes). MFCD00133992
Strem, An Ascensus Company ₹ 15,914.16
50-186-6051
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube array, multi-walled vertically aligned on Si substrate, H 0.5 mm | 308068-56-6 | 1EA
Sigma Aldrich Fine Chemicals Biosciences ₹ 73,802.34
50-186-6021
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, multi-walled >90% carbon basis, D x L 110-170 nm x 5-9 mum | Purity: >90% carbon basis | 308068-56-6 | 10G
Sigma Aldrich Fine Chemicals Biosciences ₹ 41,992.85
50-186-6025
Sigma Aldrich Fine Chemicals Biosciences Carbon Nanotube, Multi-Walled | 308068-56-6 | 1g
Sigma Aldrich Fine Chemicals Biosciences ₹ 19,075.60
50-186-6054
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube sheet aligned, size x thickness 100 mm x 100 mm x 1-5 mum | Purity: >95% (carbon) | 308068-56-6 | 1EA
Sigma Aldrich Fine Chemicals Biosciences ₹ 98,638.70
50-186-6039
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled | 308068-56-6 | MFCD00133992 | 250 mg
Sigma Aldrich Fine Chemicals Biosciences ₹ 18,865.98
50-186-6034
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled 98% (Semiconducting) | Purity: 2% (Metallic); 98% (Semiconducting) | 308068-56-6 | 1MG
Sigma Aldrich Fine Chemicals Biosciences ₹ 87,230.13
50-186-6044
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled carbon >=85 %, >70% (carbon as SWNT), diam. 1.3-2.3 nm | 308068-56-6 | 25G
Sigma Aldrich Fine Chemicals Biosciences ₹ 99,143.51
50-186-6023
Sigma Aldrich Fine Chemicals Biosciences Carbon nanotube, single-walled >70 wt. % carbon basis, D x L 2-10 nm x 1-5 mum , bundle dimensions | 308068-56-6 | 1G
Sigma Aldrich Fine Chemicals Biosciences ₹ 44,662.32
...

Related Products


Sigma Aldrich

704113

≥90% carbon basis (≥70% as carbon n...


Sigma Aldrich

704121

(7,6) chirality, ≥90% carbon basis ...


Sigma Aldrich

724777

≥90% carbon basis (≥80% as carbon n...


Sigma Aldrich

775533

≥95% carbon basis (≥99% as carbon n...


Sigma Aldrich

901634

Low metal content, avg. no. of laye...


Sigma Aldrich

901019

50-90 nm diameter, >95% carbon basi...


Sigma Aldrich

698849

>98% carbon basis, O.D. × L 6-13 nm...


Sigma Aldrich

639230

75-85% carbon basis, D × L 1.1 nm ×...

Description

  • General description: Signis® FW100 is engineered to meet the growing demand for a material with the high conductivity, large surface area, and to contain mostly double and triple walled carbon nanotubes. Applications for few-walled carbon nanotubes include advanced battery electrode additives, super/ultracapacitor materials, and more.
  • Application: Battery materials.Supplementation of lithium sulphur battery cathode materials.
  • Features and Benefits: Reinforced molecular structure.Improved electron transport.
  • Preparation Note: CoMoCAT™ synthesis process
  • Legal Information: CoMoCAT is a trademark of Chasm Advanced Materials

SAFETY INFORMATION

WGK

WGK 3

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable
