13-642-225
Thermo Scientific™ Orion™ DuraProbe™ 4-Cell Conductivity Probes
Manufacturer: Fischer Scientific
Select a Size
| Pack Size | SKU | Availability | Price |
|---|---|---|---|
| Each | 13-642-225-Each | In Stock | ₹ 77,843.85 |
13-642-225 - Each
In Stock
Quantity
1
Base Price: ₹ 77,843.85
GST (18%): ₹ 14,011.893
Total Price: ₹ 91,855.743
Cell Constant
0.475 cm^-1
Sensor Types
4 Electrode Graphite Cell
Connector Types
8-pin Mini-DIN
Diameter (English) Body
0.59 in.
Length (English) Cable
5 ft.
Material
Epoxy-Body
Min. Immersion
35 mm
Probe
Conductivity probe with built-in ATC temperature sensor
Type
4-Electrode Conductivity Cell, Mini-Din Connector
For Use With (Equipment)
Star A112, Star A122, Star A212, Star A215, Star A222, Star A322, Star A325, Star A329, Versa Star and Versa Star Pro Conductivity Meters
Description
DuraProbe 4 Cell Lab and Field Conductivity Probe, 1.5m
Diameter (Metric) Body
15 mm
Length (Metric) Cable
1.5 m
Measurement Ranges
1 μS/cm to 200 mS/cm
Storage Method
Store in distilled or deionized water between measurements; for overnight or long-term storage, thoroughly rinse and store dry
Related Products
Description
- Virtually eliminate fringe field interference errors with the advanced Thermo Scientific™ Orion™ DuraProbe™ 4-Cell Conductivity Probes
- These probes are durable and extremely accurate over a wide range of conditions
- The 4-Cell design compensates for electrode fouling, cable length, connector resistance, polarization errors, and fringe field interference errors
- These conductivity probes are ideal for high and standard conductivity samples and difficult samples such as wastewater, runoff water and mud
- DuraProbe 4-cell conductivity probes are compatible with Thermo Scientific™ Orion Star™ and Versa Star Pro™ bench and portable conductivity meters
- Paired together the instruments can be used to generate accurate, repeatable readings for conductivity, resistivity, TDS and salinity
- DuraProbe 4 Cell Lab and Field Conductivity Probes provide the highest accuracy for demanding laboratory or field applications
- The 4-electrode design compensates for electrode fouling, cable and connector resistance, polarization errors, and fringe field interference errors
- The epoxy/graphite cell material is extremely durable and chemically resistant
- DuraProbe conductivity probes are ideal for high and standard conductivity samples and difficult samples such as wastewater, runoff water and mud
- Features: Rugged epoxy body Graphite 4-cell design Built-in temperature sensor for temperature compensated conductivity measurements DuraProbe Conductivity Cells 013005MD, 013010MD have a nominal cell constant of 0.475cm - 1 ; measurement range is 1μS/cm to 200mS/cm
- DuraProbe Conductivity cells 013605MD and 013610MD have a nominal cell constant of 0.55cm - 1 ; measurement range is 10μS/cm to 200mS/cm
- Orion 4-cell conductivity probes are also compatible with: Thermo Scientific™ Orion™ Bench Conductivity Meters and Portable Conductivity Meters Thermo Scientific™ Orion™ Conductivity Standards and Solutions Thermo Scientific™ Orion™ Resister Kits and Flow Cell Accessories Recommended for: Intended for field or laboratory use Warranty : 24 months from date of purchase by Buyer or 36 months from date of shipment from Seller, whichever is earlier
