01-129-88
Welch™ ChemStar™ Vacuum Pump
Manufacturer: Welch™
Select a Size
| Pack Size | SKU | Availability | Price |
|---|---|---|---|
| Each of 1 | 01-129-88-Each-of-1 | In Stock | ₹ 8,71,343.04 |
01-129-88 - Each of 1
In Stock
Quantity
1
Base Price: ₹ 8,71,343.04
GST (18%): ₹ 1,56,841.747
Total Price: ₹ 10,28,184.787
Horsepower
0.5 hp
Model
1402
Weight (Metric)
51 kg
Frequency
60 Hz
Overall Height (Metric)
39.1 cm
Overall Length (Metric)
49 cm
Voltage
115 V
Motor Speed
525 rpm
Weight (English)
112 lb.
Flow Rate
160 L/min.
Overall Height (English)
15.4 in.
Overall Length (English)
19.3 in.
Overall Width (English)
14.1 in.
Related Products
Description
- Corrosion resistant construction of vital parts resists chemical attack
- High contamination tolerance with diluted contaminants and few moving parts Reduced frictional wear (580rpm) for cool operation Nitrogen purge to degas and cool oil Fluoroelastomer seals and gaskets Features metal vanes and stainless-steel valves Polytetrafluoroethylene coated oil case Features 115V 60Hz, 1ph explosion-proof motor Free air displacement of 160L/min at 5.6cfm Ultimate vacuum, 13.3MPa (1 × 10 -4 torr) Features gas ballast with 525rpm pump 2.1L oil capacity Tubing needed with 13/16 in
- I.D
- ISO exhaust and intake flange is NW 25 Dimensions: 19.3L x 14.1W x 15.4 in
- H (49 x 35.3 x 39.1cm) Note: This is an explosion proof model that must be hardwired
- It doesn't have a power cord or plug.
Compare Similar Items
Show Difference
Horsepower: 0.5 hp
Model: 1402
Weight (Metric): 51 kg
Frequency: 60 Hz
Overall Height (Metric): 39.1 cm
Overall Length (Metric): 49 cm
Voltage: 115 V
Motor Speed: 525 rpm
Weight (English): 112 lb.
Flow Rate: 160 L/min.
Overall Height (English): 15.4 in.
Overall Length (English): 19.3 in.
Overall Width (English): 14.1 in.
Horsepower:
0.5 hp
Model:
1402
Weight (Metric):
51 kg
Frequency:
60 Hz
Overall Height (Metric):
39.1 cm
Overall Length (Metric):
49 cm
Voltage:
115 V
Motor Speed:
525 rpm
Weight (English):
112 lb.
Flow Rate:
160 L/min.
Overall Height (English):
15.4 in.
Overall Length (English):
19.3 in.
Overall Width (English):
14.1 in.
Horsepower: 0.01 hp
Model: MD 1C
Weight (Metric): 7.9 kg
Frequency: 50/60 Hz
Overall Height (Metric): __
Overall Length (Metric): __
Voltage: 100/115/220/230 V
Motor Speed: __
Weight (English): 17.4 lb.
Flow Rate: 0.8 to 0.9 CFM
Overall Height (English): __
Overall Length (English): __
Overall Width (English): __
Horsepower:
0.01 hp
Model:
MD 1C
Weight (Metric):
7.9 kg
Frequency:
50/60 Hz
Overall Height (Metric):
__
Overall Length (Metric):
__
Voltage:
100/115/220/230 V
Motor Speed:
__
Weight (English):
17.4 lb.
Flow Rate:
0.8 to 0.9 CFM
Overall Height (English):
__
Overall Length (English):
__
Overall Width (English):
__
Horsepower: 0.01 hp
Model: MD 1C +AK+EK
Weight (Metric): 11.0 kg
Frequency: __
Overall Height (Metric): __
Overall Length (Metric): __
Voltage: __
Motor Speed: __
Weight (English): 24.3 lb.
Flow Rate: 0.8/0.9 CFM
Overall Height (English): __
Overall Length (English): __
Overall Width (English): __
Horsepower:
0.01 hp
Model:
MD 1C +AK+EK
Weight (Metric):
11.0 kg
Frequency:
__
Overall Height (Metric):
__
Overall Length (Metric):
__
Voltage:
__
Motor Speed:
__
Weight (English):
24.3 lb.
Flow Rate:
0.8/0.9 CFM
Overall Height (English):
__
Overall Length (English):
__
Overall Width (English):
__
Horsepower: 0.11 hp
Model: MD 1
Weight (Metric): 7.3 kg
Frequency: __
Overall Height (Metric): __
Overall Length (Metric): __
Voltage: 100/115 V, 220/230 V, 120 V
Motor Speed: __
Weight (English): 16.1 lb.
Flow Rate: 0.7/0.8 cfm
Overall Height (English): __
Overall Length (English): __
Overall Width (English): __
Horsepower:
0.11 hp
Model:
MD 1
Weight (Metric):
7.3 kg
Frequency:
__
Overall Height (Metric):
__
Overall Length (Metric):
__
Voltage:
100/115 V, 220/230 V, 120 V
Motor Speed:
__
Weight (English):
16.1 lb.
Flow Rate:
0.7/0.8 cfm
Overall Height (English):
__
Overall Length (English):
__
Overall Width (English):
__
