BrandTech™ VACUUBRAND™ MZ2C NT AK M D Dry Chemistry Vacuum System
Dry vacuum system provides the essential features for basic rotary evaporation
Manufacturer: Fischer Scientific
The price for this product is unavailable. Please request a quote
Horsepower
0.18 hp
Motor Speed
1500 to 1800
Material
ETFE pump head, PTFE diaphragm, PTFE tubing, FFKM valve
Temperature (Metric) Storage
-10°C to +60°C
Weight (Metric)
13.4 kg
Temperature (Metric) Max
40°C
Flow Rate
38 L/min.
Overall Height (Metric)
31.3 cm
Overall Length (Metric)
31 cm
Enclosure Rating
IP40
Includes
Operating manual, power cord
Certifications/Compliance
CE
Model
MZ 2C NT
Weight (English)
29.5 lb.
Temperature (English) Max.
104°F
Temperature (Metric) Min.
10°C
Overall Height (English)
12.32 in.
Overall Length (English)
12.2 in.
Overall Width (English)
9.56 in.
Related Products
Description
- Powered by an MZ2C NT chemistry-design vacuum pump, this system includes an inlet catchpot and integrated gas ballast to handle condensed vapors, as well as a Bourdon (dial) vacuum gauge that provides relative pressure readings and trend indication
- A fluoropolymer valve provides safe manual flow control to match pumping speed to vapor flow to help prevent bumping
- Pumps are engineered for performance, with flowrates up to 40% higher at working vacuum levels than competitive pumps with similar free air capacity ratings Chemistry-design diaphragm vacuum pump has a flowpath constructed of materials with excellent corrosion resistance, such as PTFE heads and diaphragms It is also equipped with a gas ballast to provide consistent pump performance with condensed vapors with minimal compromise of ultimate vacuum Eliminates the misting, handling, and disposal of contaminated oil associated with rotary vane pumps Typical service intervals are from 10,000-15,000 operating hours — years in many applications Flow control and solvent recovery accessories are also made of premium, corrosion-resistant materials, such as borosilicate glass for the catchpot Ultimate vacuum: 5 Torr (7mbar) Free air capacity: 38 lpm (1.4cfm) Electrical requirements: 120V, US plug Warranty and Services One year
