Nasco Sludge Judge™ Liquid Sampler Complete Unit

Description

• The Sludge Judge™ is designed to take accurate readings of settleable solids, 5% or less, in a variety of liquids, to any depth
• Ideal for sewage treatment plants, chemical plants, and food processing facilities - anywhere that accurate sample levels of settleable solids in noncaustic materials are needed Unit holds approximately 3 oz
• per foot (89 mL per 0.31 m) The Sludge Judge™ comes in 5 ft
• (1.53 m) sections of 3/4 in
• (1.90 cm) plastic pipe with screw-type connectors
• The top section includes a nylon rope for raising and lowering the sampler
• Individual sections can be combined as required to achieve the length needed
• Do not use in liquids over 165°F (74°C) Not autoclavable To use: 1
• Slowly lower the Sludge Judge™ to the bottom of the tank
• The float valve opens, allowing materials to flow in
• When the bottom has been reached and the pipe has filled to the surface level, tug slightly on the rope as the unit is raised
• This sets the check valve, trapping the mixture inside
• 2
• When the unit has been raised clear of the liquid, the amount of solids in the sample can be read using the 1 ft
• (0.31 m) increments marked on the pipe sections
• To release the material in the unit, touch the pin extending from the bottom section against a hard surface
• This opens the check valve to drain the sample.
