BT-AF1000A
Agilent BioTek MicroFill 96-/384-Well Microplate Dispenser
Manufacturer: Agilent BioTek
The price for this product is unavailable. Please request a quote
Accuracy
1μL typical at 5μL, 1μL typical at 20μL, 1% typical at 100μL
Certifications/Compliance
CE and TUV marked. RoHS compliant.
Increments
1 μL
Model
AF1000A
Plate Type
24, 96 and 384-well plates
Software
Interface software for robotic system integration
Temperature (English)
59°F to 95°F
Volume (English) Bottle
33.81 oz.
Width (English)
15 in.
Height (Metric)
17.8 cm
Depth (Metric)
45.7 cm
Weight (Metric)
9.1 kg
Product Type
Microplate Dispenser
Volume (Metric)
5 to 6000 μL
Interface
2 x 24 LCD character screen, 25 alphanumeric soft keys
Operating Conditions
80% Humidity
Precision
<5% CV typical at 5μL, <2.5% CV typical at 20μL, <1% CV typical at 100μL
Speed
10 μL/well, 96-wells, 1 x 16 : 4 s, 5 μL/well, 384-wells, 1 x 16 : 7 s
Temperature (Metric)
15°C to 35°C
Volume (Metric) Bottle
1 L
Height (English)
7 in.
Depth (English)
18 in.
Weight (English)
20 lb.
Voltage
100/240 V
Related Products
Description
- MicroFill is an economical, compact, and reliable dispenser for 24-, 96-, and 384-well microplates
- An autoclavable fluid path is ideal for applications that require sterility
- The dispense flow rates are easily selected to accommodate sensitive cell-based assays or vigorous dispensing for ELISA Accurate and precise dispensing are guaranteed, without the time-consuming recalibration, cassette replacement, and maintenance commonly associated with other dispensers
- Intuitive, on-board software is easy to use and saves time in instrument setup.
