18-888-339
Haws™ Thermostatic Mixing Valve
Manufacturer: Haws™
Select a Size
| Pack Size | SKU | Availability | Price |
|---|---|---|---|
| Each of 1 | 18-888-339-Each-of-1 | In Stock | ₹ 3,05,982.00 |
18-888-339 - Each of 1
In Stock
Quantity
1
Base Price: ₹ 3,05,982.00
GST (18%): ₹ 55,076.76
Total Price: ₹ 3,61,058.76
Certifications/Compliance
ASSE 1071, ANSI Z358.1, CSA B125.3, NSF/ANSI 372, NSF/ANSI 61-section 8, California Health and Safety Code 116875 (AB 1953).
For Use With (Application)
Emergency Showers and Eyewash Equipment
Height (Metric)
20.32 cm
Material
Brass
Pressure
125 psi
Width (English)
5 in.
Flow Rate
20 gpm, 31 gpm
Height (English)
8 in.
Inlet Connection (Metric)
1 in.
Outlet Connection (English)
1.25 in.
Product Type
Thermostatic Mixing Valve
Width (Metric)
12.7 cm
Related Products
Description
- Flow rate of 1 to 31 gpm (3.8 to 117.3 L) for better temperature control across the operating range AXION's superior design and technology provide a complete safety solution for increased victim comfort
- Lowest internal pressure drop for this class of valve (advantage where supply pressure is low) Wax based thermostat technology for fast response time with proven highly reliable temperature control Highest Cold Water Bypass flow rate in the industry (65% of rated tepid flow rate) Modular lead-free brass design with internal check stops Over-sized valve seats resist failures caused by foreign matter New, efficient shuttle design eliminates valve sticking Custom funnel design improves temperature control at low flow rates Outlet temperature is factory set to 85°F (29°C).
