6990029
LABOMED™ MET 400 Inverted Metallurgical Microscope
High-precision metallurgical tool for demanding environments. LABOMED™ MET 400 Inverted Metallurgical Microscope is ideal for daily inspection of heat-treated and stress-tested metals, glass, plastics, and chemicals.
Manufacturer: Fischer Scientific
The price for this product is unavailable. Please request a quote
Eyepiece
10X/22 mm with Foldable Eyeguard
Magnification Power
5X, 10X, 20X, 50X (100X optional)
Product Type
Microscope
For Use With (Application)
Education, Metallurgical, Material Sciences
Nosepiece
Reverse angle quadruple nosepiece
Lighting Type
Koehler Episcopic Illumination System with Diffuser, Halogen 6V/30w with intensity control
Model
MET 400
Resolution
Coarse and fine
Includes
Power cable (6 ft.), Nylon dust cover and cleaning cloth, Styrofoam casing
Electrical Requirements
110/240 V
Related Products
Description
- Stand: Ergonomic sturdy stand made of anti-rust material Viewing Body: Siedentopf binocular or trinocular head 30° inclined, fixed IPD: 52 - 75mm Eyepiece: Focusable wide field eyepieces 10x/22mm, with foldable eye guard, antifungal Nosepiece: Reverse angle quadruple nosepiece with click stops and rubber grip Objectives: ML series infinity corrected, DIN Plan Achromatic objectives 5x, 10x, 20x and 50x Antifungal, MaxLite (TM) coated Optional 100x dry objective Focus: Coaxial coarse and fine focusing system with tension adjustment Focus graduation is 2um per division Illumination: Koehler episcopic illumination system with diffuser Halogen 6V-30w with intensity control 100V - 240V universal power supply Stage: Fixed stage with specimen holder - 3 types (38mm, 55mm, 65mm) Optional mechanical stage Electrical Requirements: Universal power supply (110V-240V) with built-in voltage stabilizer Optional: 100x dry objective, Mechanical stage, Adapters for video and digital cameras
Compare Similar Items
Show Difference
Eyepiece: 10X/22 mm with Foldable Eyeguard
Magnification Power: 5X, 10X, 20X, 50X (100X optional)
Product Type: Microscope
For Use With (Application): Education, Metallurgical, Material Sciences
Nosepiece: Reverse angle quadruple nosepiece
Lighting Type: Koehler Episcopic Illumination System with Diffuser, Halogen 6V/30w with intensity control
Model: MET 400
Resolution: Coarse and fine
Includes: Power cable (6 ft.), Nylon dust cover and cleaning cloth, Styrofoam casing
Electrical Requirements: 110/240 V
