SEBAP4BBF1
Laxco™ SeBa™ Pro4B Series Digital Microscope System
Manufacturer: Laxco™
Select a Size
| Pack Size | SKU | Availability | Price |
|---|---|---|---|
| Each of 1 | SEBAP4BBF1-Each-of-1 | In Stock | ₹ 13,59,035.04 |
SEBAP4BBF1 - Each of 1
In Stock
Quantity
1
Base Price: ₹ 13,59,035.04
GST (18%): ₹ 2,44,626.307
Total Price: ₹ 16,03,661.347
Condenser Type
1.2 N.A. Abbe, with Iris Diaphragm and Flip out lens with 0.9 N.A.
Design Type
Contrast Method: Brightfield
Display Type
9.7 in. Retina
Head Style
SeBa Pro 4 Display Binocular
Magnification Power
4X, 10X, 20X, 40X, 100X (oil)
Product Type
Microscope
For Use With (Application)
Advanced Research, Clinical, Lab
Optical Design
Infinity, DIN
Width (English)
10.5 in.
Height (English)
24.3 in.
Diameter (English)
18.8 in.
Electrical Requirements
External, 110/220 V Auto Switch 12 V, DC Supply
Description
Right-Handed, X/Y Rackless Mechanical Stage
Camera Type
16MP Color
Eyepiece
20 mm FOV
Lighting Type
LED
Model
SeBaP4B-BF1
Resolution
Coarse and Fine
Includes
Stand, Dust Cover, Objectives, Power Cord, Immersion Oil, USB Drive, filters, keyboard, mouse
Warranty
5 years optical and mechanical, 1 year electrical from date of purchase
Width (Metric)
26.7 cm
Height (Metric)
61.8 cm
Diameter (Metric)
47.7 cm
Related Products
Description
- Head 9.7 in
- touchscreen retina display 16MP color CMOS camera 4 USB ports for attaching keyboard, mouse, storage device or remote capture button SeBaAccess technology allows for individual log in, via an access card swipped in front of the Seba label SeBaShare cloud based storage allows simple uploading of images to unique account on the cloud for accessing of images anywhere (log in based off from SeBaAccess) Capture still or video images and save them to SeBaShare or USB storage device Capture, review, measure, and annotate images Single power source controls power to the camera, computer and microscope Objectives Sealed 40X to prevent accidental damage from use of oil at 100X Infinity corrected Anti-reflective optical coatings, for superior optical quality Parfocal and parcentered Stand Built-in carrying handle Reverse objective turret (5 position) allows for easy access to slides Adjustable focusing stop protects slides from accidental damage Reflected LED transmitted illumination with removable housing Rackless X/Y mechanical stage for smooth, fine movement control Illumination Full Koehler illumination with field diaphragm Cool, stable, color temperature and brightness intensity 50,000 bulb life Certifications Quality Performance Certification
