Aervent® 0.2 µm, Cartridge
pore size 0.2 μm, cartridge nominal length 5 in. (13 cm), Code 7
Manufacturer: Millipore
Synonym(S): Aervent CTGR Cartridge Filter 5 in. 0.2 µm Code 7
Select a Size
| Pack Size | SKU | Availability | Price |
|---|---|---|---|
| 1 EA | CTGR75S01-1-EA | In Stock | ₹ 51,176.27 |
CTGR75S01 - 1 EA
In Stock
Quantity
1
Base Price: ₹ 51,176.27
GST (18%): ₹ 9,211.729
Total Price: ₹ 60,387.999
material
PTFE polypropylene polypropylene supportsilicone seal
Quality Level
400
sterility
non-sterile
Sterilization Compatibility
steam-in-place compatible
product line
Aervent®
feature
hydrophobic
manufacturer/tradename
Aervent®
parameter
≤12 mL/min nitrogen diffusion at 970 mbar (14 psig) and 23 °C (in 70/30% IPA/water)1.7 bar max. inlet pressure (25 psi) at 80 °C1.8 bar max. differential pressure (25 psid) at 80 °C (Forward)4.1 bar max. differential pressure (60 psid) (Reverse; intermittent)4.1 bar max. inlet pressure (60 psi) (Reverse; Intermittent)5.5 bar max. differential pressure (80 psid) at 25 °C (Forward)5.5 bar max. inlet pressure (80 psi) at 25 °C (Forward)
technique(s)
gas filtration: suitable
L
5 in.
Related Products
Description
- General description: Device Configuration: Cartridge
- Features and Benefits: Rated for aerosol retention of a total challenge of 108–1010 plaque forming units of ΦX-174 virus particles at 85 Nm3/h (50 SCFM) per cartridge.
- Packaging: Double Easy-Open bag
- Quality: Retains Brevundimonas diminuta liquid aerosol for 21 days at a minimum challenge of 10⁷ CFU/cm²
- Preparation Note: Sterilization Method150 (100 forward/50 reverse) SIP cycles of 30 min @ 145 °C
- Analysis Note: Bacterial RetentionSamples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
- Other Notes: Directions for UseOrganism Retention: MicroorganismMode of Action: Filtration (size exclusion)Application: BioProcessingIntended Use: Reduction or removal of microorganism/bioburdenInstructions for Use: Please refer Steam Sterilization & Integrity Testing Procedures guide and first page of Visual Inspection GuideStorage Statement: Store in dry locationDisposal Statement: Dispose of in accordance with applicable federal, state and local regulations.
- Legal Information: AERVENT is a registered trademark of Merck KGaA, Darmstadt, Germany
Compare Similar Items
Show Difference
material: PTFE polypropylene polypropylene supportsilicone seal
Quality Level: 400
sterility: non-sterile
Sterilization Compatibility: steam-in-place compatible
product line: Aervent®
feature: hydrophobic
manufacturer/tradename: Aervent®
parameter: ≤12 mL/min nitrogen diffusion at 970 mbar (14 psig) and 23 °C (in 70/30% IPA/water)1.7 bar max. inlet pressure (25 psi) at 80 °C1.8 bar max. differential pressure (25 psid) at 80 °C (Forward)4.1 bar max. differential pressure (60 psid) (Reverse; intermittent)4.1 bar max. inlet pressure (60 psi) (Reverse; Intermittent)5.5 bar max. differential pressure (80 psid) at 25 °C (Forward)5.5 bar max. inlet pressure (80 psi) at 25 °C (Forward)
technique(s): gas filtration: suitable
L: 5 in.
