CD131 Mouse anti-Human, Brilliant Violet 711, Clone: 3D7, BD Optibuild™

Description

• The 3D7 antibody reacts with CD131, the 120 kD commonβchain (βc) which is shared with the receptor complexes for human granulocyte-macrophage colony stimulating factor (GM-CSFR), interleukin-3 (IL-3R) and interleukin-5 (IL-5R)
• Together with theαsubunit of either the IL-3R (IL-3Rα), IL-5R (IL-5Rα), or GM- CSFR (GM-CSFRα), the commonβchain forms high-affinity, signaling receptors for human IL-3, IL-5 and GM-CSF, respectively
• Cell surfaceβc are expressed by a variety of different cell types including hematopoietic progenitor cells derived from pluripotent stem cells, monocytes, neutrophils, eosinophils, basophils, endothelial cells, fibroblasts, and Langerhans cells
• The immunogen used to generate this hybridoma was cells co-transfected with expression vectors which contained cDNA for the human IL-3αandβchains
• The antibody was conjugated to BD Horizon™ BV711 which is part of the BD Horizon Brilliant™ Violet family of dyes
• This dye is a tandem fluorochrome of BD Horizon BV421 with an Ex Max of 405nm and an acceptor dye with an Em Max at 711nm
• BD Horizon BV711 can be excited by the violet laser and detected in a filter used to detect Cy™5.5 / Alexa Fluor™ 700-like dyes (eg, 712/20nm filter)
• Due to the excitation and emission characteristics of the acceptor dye, there may be moderate spillover into the Alexa Fluor™ 700 and PerCP-Cy5.5 detectors
• However, the spillover can be corrected through compensation as with any other dye combination
• BV711 is a tandem fluorochrome of BD Horizon BV421 and an acceptor dye with an emission maximum at 711 nm
• This dye offers a very bright choice for the violet laser
• Due to the excitation and emission characteristics of the acceptor dye, there may be moderate spillover into the Alexa Fluor™ 700 and PerCP-Cy5.5 detectors
• BV711 will also have moderate spillover into the BD Horizon Brilliant™ Violet 786 detector.
